The LW Scientific Innovation Biological Microscope is a premium laboratory instrument designed for advanced biological and clinical research. Featuring professional-grade optics, ergonomic design, and reliable illumination, this microscope delivers crisp, detailed images for demanding lab environments including diagnostic labs, research institutions, and higher education.

Overview

The Innovation microscope is built for high-performance microscopy with Infinity Plan Achromatic objectives, a comfortable Siedentopf binocular head, and precision mechanical controls. Its powerful LED illumination system ensures bright, evenly lit images with minimal heat generation, making it ideal for long viewing sessions. With its sleek design and durable construction, the Innovation series is engineered to meet the needs of serious professionals and academic labs alike.

Key Features

• Infinity Plan Achromatic objectives (4x, 10x, 40x, 100x oil)
• Siedentopf binocular head inclined at 30°, 360° rotatable
• Widefield 10x/22mm eyepieces with diopter adjustment
• Powerful LED illumination with adjustable brightness
• Mechanical stage with low-position X-Y coaxial controls
• Coaxial fine and coarse focus knobs for precise control
• 1.25 NA Abbe condenser with iris diaphragm and filter holder
• Rugged metal frame designed for daily laboratory use

Product Specifications

• Head: Binocular Siedentopf, 30° inclined, rotatable
• Objectives: Infinity Plan Achromatic (4x, 10x, 40x spring, 100x oil spring)
• Eyepieces: WF10x/22mm with diopter adjustment
• Illumination: LED with intensity control
• Stage: Mechanical with low-position coaxial controls
• Condenser: Abbe 1.25 NA with iris diaphragm
• Focus: Coaxial coarse and fine focus
• Construction: Durable metal frame
• Power: 110V or 220V
• Warranty: 5-year limited (1-year electrical components)

Ideal For

• Clinical and diagnostic laboratories
• Biological and life science research
• Higher education and academic institutions
• Veterinary labs and healthcare training programs
• General laboratory microscopy applications
