Rigel Medical 288+ Electrical Safety Analyzer

The Rigel 288+ Electrical Safety Analyzer offers a fast, reliable, and highly accurate solution for verifying the electrical safety of medical devices. Engineered to meet both international and local safety standards, including IEC 60601 and IEC 62353, this compact analyzer is ideal for clinical, field, and service environments requiring consistent compliance and dependable performance.

Overview

Designed with flexibility and ease of use in mind, the Rigel 288+ operates entirely on standard AA batteries, eliminating the need for mains power and enabling complete freedom of movement. Its portable design makes it perfect for use in hospitals, clinics, and hard-to-reach areas. Supporting a comprehensive range of essential safety tests—including insulation resistance, earth/ground bond, and touch leakage current—the Rigel 288+ ensures technicians can perform efficient testing wherever and whenever needed.

Key Features

• Performs insulation resistance, earth/ground bond, and leakage current tests
• Battery-powered operation allows testing without a mains connection
• Supports IEC 60601 and IEC 62353 compliance for global compatibility
• Compact and lightweight for enhanced portability and convenience
• Quick, accurate test sequences for efficient field service operations
• Simple user interface designed for ease of use in clinical environments
• Ideal for preventative maintenance and routine safety verification

Product Specifications

• Dimensions: Approx. 220 × 200 × 75 mm
• Weight: Approximately 1.5 kg
• Power: Battery operated (standard AA batteries)
• Material: Durable ABS plastic housing
• Compliance: Meets IEC 60601, IEC 62353, and local safety standards
• Test Capabilities: Insulation resistance, earth/ground bond, touch/point-to-point leakage
• Display: User-friendly interface for fast setup and operation

Ideal For

• Hospitals and clinical engineering departments
• Biomedical service and maintenance teams
• Outpatient and mobile testing environments
• Medical equipment compliance and safety verification
• Field service technicians and mobile calibration teams
