Rigel Medical Uni-Therm Electrosurgical Analyzer

The Rigel Uni-Therm is a high-performance electrosurgical analyzer designed to deliver precise and reliable performance testing of electrosurgical generators. Ideal for use in hospitals, biomedical engineering departments, and surgical equipment service centers, the Uni-Therm ensures accurate measurements of high-frequency leakage, power output, and patient return plate safety functions—all in one standalone device.

Overview

Engineered for precision and ease of use, the Rigel Uni-Therm features a large, full-color graphical display and intuitive controls, allowing for safe and efficient operation during routine testing or advanced diagnostics. It incorporates an ultra-low inductive load bank to provide highly accurate, stable test conditions under high-frequency currents. Whether performing single tests or executing automated sequences, users can store, review, and export test data directly from the instrument—enhancing documentation and workflow efficiency.

Key Features

• Accurate testing of electrosurgical generators for high-frequency leakage, output power, and distribution
• Integrated patient return plate alarm testing for safety assurance
• Ultra-low inductive load bank provides highly stable testing conditions
• Large, full-color graphical display for clear readings and intuitive navigation
• Standalone operation—no external PC required for test execution or data management
• Supports both manual and automated test sequences
• Onboard data storage and export capabilities for test documentation

Product Specifications

• Dimensions: Approx. 330 × 280 × 110 mm
• Weight: Approx. 4.5 kg
• Display: Full-color graphical LCD
• Load Bank: Ultra-low inductive for stable high-frequency current testing
• Test Capabilities: HF leakage, output current and power, power distribution, plate alarm
• Operation: Standalone unit with manual and automatic test modes
• Data Management: Internal storage with viewing and transfer capabilities
• Compliance: Designed to meet international electrosurgical safety testing standards

Ideal For

• Hospitals and surgical centers
• Biomedical engineering and clinical service teams
• Electrosurgical equipment manufacturers
• Calibration and safety verification service providers
• Medical device quality control departments
• Mobile and field-based service technicians
