Zoll R-Series BLS Defibrillator

The ZOLL R-Series BLS Defibrillator is a versatile monitor-defibrillator tailored for Basic Life Support and first-responder scenarios. Featuring one-button AED operation with an optional manual mode, Real CPR Help®, and OneStep™ electrodes, it ensures effective life-saving interventions in hospitals, EMS units, and clinics.

Overview

Designed for ease and lifesaving accuracy, the R-Series BLS provides AED simplicity for untrained users, while trained professionals can switch to manual mode for advanced care. Real CPR Help® offers real-time guidance on compression depth and rate, and See-Thru CPR® lets responders analyze heart rhythms during compressions. The OneStep™ electrode system enables pacing, ECG, and defibrillation with a single pad set.

Key Features

• One-button AED interface: Guides rescuers through shocks quickly and confidently, then switches to manual mode when advanced care arrives.
• Real CPR Help® & See-Thru CPR®: Provides depth/rate feedback and rhythm visibility during compressions.
• OneStep™ electrodes: Simplifies use with multifunctional pads for ECG, pacing, and defibrillation.
• Pediatric optimization: Automatically adjusts energy and algorithm settings with pediatric electrodes.
• Rectilinear Biphasic waveform: Delivers up to 200 J with impedance-adaptive energy delivery.
• Rapid charge: Charges to full energy within 7 seconds with fresh battery.
• Data capture & connectivity: Stores ECG, CPR data, and event logs; export via USB/CompactFlash with optional Wi‑Fi and dashboard integration.
• Built for readiness: Self-tests and Code Readiness features ensure operational status at all times.

Product Specifications

• Power output: 1–200 J, rectilinear biphasic waveform for consistent energy delivery
• Charge time: < 7 seconds to 200 J (fresh battery)
• Display: 6.5″ color LCD, sweep speed 25 mm/s
• Weight: ~13.6 lb (6.2 kg) without paddles; ~15.2 lb (6.9 kg) with paddles
• Dimensions: 12.5″ × 10.5″ × 8.2″
• Battery: SurePower™ rechargeable lithium-ion; over 4 hours ECG monitoring or 100 full-energy charges
• Electrode system: OneStep™ multifunction pads (adult/pediatric)
• Data storage: Internal memory plus USB/CompactFlash export; optional Wi‑Fi
• Connectivity: USB, CF card, Wi‑Fi, compatible with Defibrillator Dashboard
• Certifications: UL 60601, AAMI DF80, IEC 60601-2-4/2-25/2-27
• Warranty: Standard 5-year coverage

Ideal For

• Hospital code carts, EDs, and ICUs
• EMS and ambulance services for BLS with ALS upgrade capability
• Clinic and office-based emergency response
• Pediatric and adult resuscitation with auto-adjust energy
• Training programs and facilities utilizing CPR quality feedback
