High Flow Mixer Air Oxygen - Model 3600/3601 - Sechrist

Wall or Pole Mount

Standard Parts:
Water Trap Assembly

Optional Parts:
14ft air hose/14ft oxygen hose**,
both with DISS fittings
**Not CE marked.

Provides for precise mixing of air and oxygen for many clinical applications. Models 3600 and 3601 are high flow mixers designed for general applications. 3601 utilizes a wall mount configuration and 3600 provides for pole mounting.

Accuracy*: +/- 3% • Maximum Flow at 60% FIO2 and 50 psig • Maximum Flow: 100 LPM

Bleed Flow: 8 - 10 LPM @ 16 LPM Flow Rate • FIO2 Range: 0.21 +0.01 to 1.0

Gas Supply Range: 50 psig +/- 20 psig
