The Mindray Gas Module SE is a compact, sidestream gas analyzer designed to deliver real-time, breath-by-breath monitoring of anesthetic agents and respiratory gases. Ideal for integration into clinical environments such as operating rooms and post-anesthesia care units, this module enhances patient safety by providing accurate and timely gas measurements.

Overview

Engineered for seamless compatibility with Mindray's Passport 2, Spectrum, and Spectrum OR monitors, the Gas Module SE identifies and quantifies concentrations of O₂, CO₂, N₂O, and five anesthetic agents: Halothane, Isoflurane, Sevoflurane, Desflurane, and Enflurane. Utilizing a non-dispersive infrared analyzer, it ensures precise measurements essential for effective anesthesia management.

Key Features

• Breath-by-breath analysis for real-time monitoring
• Automatic identification of five anesthetic agents
• Non-dispersive infrared technology for accurate gas detection
• Compact and lightweight design for easy integration
• Compatible with Mindray Passport 2, Spectrum, and Spectrum OR monitors
• Water trap system removes moisture and impurities from samples
• Automatic compensation for pressure and gas collision broadening effects
• Quick warm-up time: operational within 2 minutes for CO₂, O₂, and N₂O

Product Specifications

• Dimensions: 4.2" H x 11.85" W x 10" D (10.6 cm x 30.1 cm x 25.4 cm)
• Weight: 9.6 lbs (4.35 kg)
• Sampling Rate: 200 ± 20 ml/min (with sampling line ≤ 6 meters)
• Sampling Delay: 2.5 seconds (with a 3-meter sampling line)
• Total System Response Time: 2.9 seconds (including sampling delay and rise time)
• Display Update Rate: Breath-by-breath
• Compliance: Meets IEC 60601-1-2 standards
• Power Supply: 100–240 VAC, 50–60 Hz

Ideal For

• Operating rooms
• Post-anesthesia care units (PACU)
• Ambulatory surgical centers
• Intensive care units (ICU)
• Outpatient surgical facilities
