Schiller ERG 911 S Plus Ergometer Bicycle

The Schiller ERG 911 S Plus is a versatile, recumbent-style ergometer designed for clinical cardiopulmonary diagnostics, rehabilitation, and stress testing. Featuring a user-friendly LCD display and robust construction, it supports seamless integration with Schiller ECG systems and stands alone for independent testing.

Overview

With a load range of 20–999 W and speed-independent resistance, the ERG 911 S Plus delivers precise control for both protocol-based and manual stress tests. It features a low-entry frame, stable steel/aluminum build, and compatibility with 115 or 230 VAC systems. It can operate standalone (“smart”) or controlled remotely (“easy”) via ECG/PC connection.

Key Features

• Load range 20–999 W: Wide power spectrum supports diverse testing requirements
• Large LCD display: 10 cm × 7.5 cm graphic screen offers clear test data
• Seamless Schiller integration: Galvanically isolated RS‑232 interface to ECG/workstation systems
• Robust design: Steel/aluminum frame supports up to 160 kg patient weight
• Low-entry, patient-friendly: Quiet, belt-drive system and low entry height for easy access
• Dual operation mode: Standalone smart mode or master-controlled easy mode
• Optional accessories: Electric saddle adjustment, BP module, SpO₂ support, child/adult cuffs

Product Specifications

• Model/SKU: 2.210076 (ERG 911 S Plus)
• Power: 115 or 230 VAC, 50/60 Hz
• Load range: 20–999 W, ±3 W accuracy
• Display: 10 × 7.5 cm graphic LCD
• Patient weight capacity: Up to 160 kg (353 lb)
• Frame type: Low-entry recumbent frame, steel/aluminum
• Drive: Speed-independent belt drive, near-silent operation
• Interface: RS‑232 galvanic isolation (ECG/PC control)
• Dimensions: Compact footprint, low-profile base
• Weight capacity: Approx. 60 kg device weight, 160 kg patient capacity
• Warranty: 1 year standard

Ideal For

• Cardiac and pulmonary stress test laboratories
• Rehabilitation and sports medicine clinics
• Elderly, mobility-challenged, or high body-weight patients (up to 160 kg)
• Integration with Schiller ECG/workstation systems
• Standalone testing scenarios in clinics or rehab centers
