Welch Allyn RetinaVue 700 Imager

The Welch Allyn RetinaVue 700 Imager is the world’s most advanced handheld retinal camera, designed for fast, non-mydriatic imaging in primary care, clinics, and mobile healthcare settings. Featuring auto-alignment, auto-focus, and auto-capture, it enables efficient, high-quality retinal examinations with minimal training.

Overview

Utilizing a 60° field of view and capturing through pupils as small as 2.5 mm, the RetinaVue 700 delivers detailed fundus images without the need for dilation. Smart camera functionality assesses pupil size and lens clarity, helping avoid retakes. Equipped with secure, bi-directional Wi‑Fi and EMR connectivity, it integrates effortlessly into clinical workflows, and images are managed via the HIPAA-compliant RetinaVue Network software.

Key Features

• Auto-alignment, auto-focus & auto-capture: Three-axis motor system simplifies image acquisition.
• Large 60° field of view: Covers more retinal area—up to 75% larger than many handheld alternatives.
• 2.5 mm small-pupil capability: Minimizes or eliminates need for pharmacologic dilation.
• Smart camera alerts: Built-in checks warn of small pupils or dirty lenses to optimize image quality.
• High-resolution imaging: 5 MP photos at 2592×1944 pixel resolution.
• Portable handheld design: Ergonomic body with intuitive touch controls and hands-free operation.
• Secure network integration: Wireless EMR and cloud connectivity with end-to-end encryption.
• Care delivery model compatible: Designed for teleretinal programs, increasing exam completion and reducing vision care gaps.

Product Specifications

• Field of view: 60° retinal
• Pupil size requirement: ≥ 2.5 mm
• Image resolution: 5 MP (2592 × 1944 pixels) [spec sheet]
• Display: 4.3″ color touchscreen for preview and feedback
• Dimensions: Approx. 11.4″ L × 6.6″ W × 4.8″ H (290 × 167 × 106 mm)
• Weight: ~2.8 lb (standard battery), up to ~3.0 lb (high-capacity battery)
• Illumination: Infrared preview LED; natural-white LED for capture
• Pupil alignment: Automatic and manual focus modes
• Connectivity: Built-in Wi‑Fi for EMR/RetinaVue Network; USB port for charging and data transfer
• Software: Requires RetinaVue Network subscription for secure image storage, interpretation, and EMR integration
• Standards compliance: ISO 10940 optical standard; HIPAA/HITECH encryption; FDA-cleared for teleretinal exams

Ideal For

• Primary care, community clinics, and mobile health units
• Diabetic retinal screening in non-eye care settings
• Programs requiring secure EMR and cloud connectivity
• Settings prioritizing patient comfort, avoiding dilation
• Teleretinal service providers closing population health gaps
